HGFK Anti-Drifting Turning Roller

Model	Max. Loading (t)	Working Range (mm)	Roller Sizes (D × W) (mm)		Motor Power (Kw)	Roller Linear Speed (m/h)
			Rubber	Metallic
HGFK40	40	￠600-4200	￠400 × 120	￠394 × 60	1.1 × 2	6-60 VFD
HGFK60	60	￠750-5000	￠450 × 120	￠444 × 70	1.5 × 2
HGFK100	100	￠800-6000	￠550 × 120	￠538 × 100	2.2 × 2
HGFK160	160	￠1000-6000		￠620 × 220	3 × 2
HGFK250	250	￠1000-7000		￠700 × 260	4 × 2
HGFK400	400	￠1000-7500		￠800 × 300	5.5 × 2
HGFK500	500	￠1000-8000		￠800 × 300	7.5 × 2
HGFK630	630	￠1000-8500		￠850 × 350	11 × 2
HGFK800	800	￠1500-9000		￠900 × 350	15 × 2
HGFK1000	1000	￠1500-10000		￠950 × 350	15 × 2
HGFK1250	1250	￠2000-15000		￠1100 × 400	22 × 2
HGFK1600	1600	￠2000-15000		￠1200 × 400	30 × 2

Anti-drift turning rolls are used for welding thick-wall and narrow gap shells. They are also applicable for preventing the work-piece from drifting axially. Adopting radial movement or adjustment, this anti-drift turning roll has compact structure, nice appearance and small correction power. Anti-drifting accuracy is ≤±2 mm. As a turning roll manufacturer and supplier, we also provide self-alignment anti-drift turning roller, bolt-adjustable welding rotator and screw-adjustable turning roller for sale.
